Installation¶

It is recommended to visit the hardware and software prerequisites to learn more about deployment options and hardware requirements.

Prerequisites¶

The system can be installed on any OS that supports docker, however the recommended OS is Ubuntu 22.04. The steps described below assume an Ubuntu 22.04 installation.

1. System update¶

Make sure your system is up-to-date.

sudo apt update && \
sudo apt upgrade -y && \
sudo reboot

2. Install docker¶

Both indexer nodes and query nodes require docker. If your system does not have it installed, follow these steps before continuing.

3. Install NVIDIA software (indexer node only)¶

If your system does not have NVIDIA docker runtime installed, follow these steps before continuing.

Installation steps¶

1. Download deployment scripts¶

Download and extract the configuration scripts to the u-query folder.

wget https://u-query.ultinous.com/docs/r9/u_query_install.tar -P /tmp && \
sudo tar -xvf /tmp/u_query_install.tar -C / && \
sudo chgrp -R $(id -g) /opt/u-query

2. Set database password and application url¶

Create a unique password for the database, and set it in docker-compose's .env file. Examples below;

sed -i "s/\(DB_POSTGRES_PASSWORD=\)/\1$(< /dev/urandom tr -dc 'A-Za-z0-9' | head -c 27)/g" /opt/u-query/.env

sudo apt install -y pwgen && sed -i "s/\(DB_POSTGRES_PASSWORD=\)/\1$(pwgen -s 27 1)/g" /opt/u-query/.env

Open /opt/u-query/.env file and change the http://localhost value of the NEXTAUTH_URL variable to the public IP address of the machine where the software is installed.

3. Set secret for application token encryption¶

Create a secret for the application token encryption, and set it in docker-compose's .env file. Examples below;

sed -i "s/\(NEXTAUTH_SECRET=\)/\1$(< /dev/urandom tr -dc 'A-Za-z0-9' | head -c 27)/g" /opt/u-query/.env

sudo apt install -y pwgen &&  sed -i "s/\(NEXTAUTH_SECRET=\)/\1$(pwgen -s 27 1)/g" /opt/u-query/.env

4. Login to docker¶

Login to dockerhub to be able to download software components.

docker login -u <your_ultinous_provided_username>

5. Model optimization (indexer node only)¶

If the installed node is an indexer node (or standalone installation), model optimization needs to be performed; This process optimizes deep learning models for the GPU.

Execute the following commands to start model optimization:

cd /opt/u-query && \
docker compose -f build_trt.yaml pull && \
docker compose -f build_trt.yaml up

6. Download software components¶

docker compose pull && \
docker logout

7. Start Iris+ Professional services¶

docker compose up -d

sudo ufw allow 80/tcp
